Technical specifications
| Thread (UNF) | C (MM) | C (INCH) | D (MM) | D (INCH) | H (MM) | H (INCH) | Adjustment (MM) | Adjustment (INCH) | Additional Information |
|---|---|---|---|---|---|---|---|---|---|
| 1/4" | 8.5 | 0.335 | 6 | 0.236 | 6.4 | 1/4" | 76 | 2.992 | - |
| 5/16" | 9.5 | 0.374 | 6.5 | 0.256 | 8 | 5/16" | 83 | 3.268 | - |
| 3/8" | 11 | 0.433 | 7.8 | 0.307 | 9.5 | 3/8" | 92 | 3.622 | - |
| 7/16" | 12 | 0.472 | 9.3 | 0.366 | 11.1 | 7/16" | 100 | 3.937 | - |
| 1/2" | 13.5 | 0.531 | 11.5 | 0.453 | 12.7 | 1/2" | 104 | 4.094 | - |
| 5/8" | 18.3 | 0.72 | 13.6 | 0.535 | 16 | 5/8" | 126 | 4.961 | - |
| 3/4" | 22.5 | 0.886 | 18 | 0.709 | 19.5 | 3/4" | 168 | 6.615 | *Eye machined not forged |
Description
Bronze Eye & Blank represents premium rigging hardware engineered with elegant design principles and superior materials for demanding marine applications where strength, durability, and aesthetic appeal are paramount. These sophisticated fittings are forged from high-strength bronze alloy, delivering exceptional structural integrity that exceeds the strength characteristics of the wire rope systems they serve, ensuring reliable performance under extreme loads.
Available in eight thread sizes from 1/4" to 3/4" UNF with comprehensive dimensional specifications, Bronze Eye & Blank accommodates diverse rigging requirements across various vessel sizes and applications. The precise engineering ensures optimal fit and performance, with adjustment capabilities ranging from 76mm to 168mm and corresponding imperial measurements for international compatibility.
The advanced forging process creates superior grain structure and strength characteristics compared to cast alternatives, whilst the high-quality polished chromium finish provides exceptional corrosion resistance and maintains lustrous appearance throughout extended marine exposure. This premium finish also enhances the elegant design that complements traditional and contemporary vessel aesthetics.
Each fitting is supplied complete with a Threaded Eye (C770) at one end, providing immediate installation capability whilst allowing for custom termination at the blank end to suit specific rigging requirements. The 3/4" variant features eye machined rather than forged construction, reflecting the specialised manufacturing requirements for larger sizes whilst maintaining the superior strength and performance characteristics that define this premium rigging hardware series.
